Condition: new , Bernardo Topcut 3200 ER Panel Saw
Technical Specifications
Table dimensions 1100 x 735 mm
Panel table 3200 x 400 mm
Cutting length 3200 mm
Max. saw blade diameter 400 x 30 mm
Max. cutting height 90° / 45° 125 / 88 mm
Cutting width with parallel guide 1300 mm
Table height 890 mm
Table extension 600 x 615 mm
Table widening 825 x 750 mm
Extension table with roller 1240 x 860 mm
Main saw blade speed 3000 / 4000 / 5000 rpm
Scoring saw blade speed 8000 rpm
Scoring saw blade 120 x 20 mm
Dust extraction connection Ø 100 mm
Motor output S1 100% 5.5 kW (7.5 hp)
Motor input S6 40% 7.5 kW (10.0 hp)
Scoring motor output 0.75 kW
Voltage 400 V
Machine dimensions (W x D x H)
3420 x 3600 x 1610 mm
Weight approx. 850 kg
Scope of supply
• Electric saw blade height adjustment
• Digital cutting height display
• Saw blade guard with infeed roller
• Miter fence
• Eccentric clamp
• Table widening
• Extendable telescopic fence
• Longitudinal fence flaps
• Extension table with roller
• Sliding block
• Scoring unit with independent motor
• Operating tools
Features
• Powerful drive motor (5.5 kW) with high torque, designed for optimal cutting performance
• Smooth-running twin-roller carriage with center and end position locking for precise cuts
• Maximum saw blade diameter 400 mm for cutting heights up to 125 mm
• Extension table with roller for simplified handling of larger workpieces
• Foldable parallel guide with micrometer fine adjustment (advantageous for large panels)
Robybq A Nod N S T Doxsch
• Standard equipment includes a separately driven scoring unit (motor output 0.75 kW)
• Stable saw unit with pivot elements made of gray cast iron, guided on both sides
• Table widening for cutting widths up to 1300 mm included in the scope of supply
• All aluminum parts (panel table, fences, etc.) are anodized
• Extendable telescopic fence (up to 3200 mm) can be mounted on the extension table at the front and rear, infinitely adjustable from 90° to 45°
Intermediem vanzarea acestui utilaj industrial. La cerere, putem asigura transport specializat la destinatie, punere in functiune si pachete de garantie viitoare. Contact direct: Danut Stroie, Telefon / WhatsApp: +40 741 955 772, Email: masiniuneltedevanzare@gmail.com.
