Condition: used , Tenoning spindle 2 Stk.
Number of milling agregates 5 St.
Spindle diameter 50 mm
Control Weinig, PC-Nexus
Weinig Unicontrol 10 NC Window System — Optional: Extensive Tooling Set
-----
Optionally available (at an additional cost):
IV 68 Wood, Wood/Aluminum
IV 78 Wood, Wood/Aluminum
IV 68 Entrance Doors
Manufacturer's Technical Description:
-----
Item 1: Weinig Unicontrol 10 NC Window System
-----
Cross-cut Saw
-----
with laser alignment light; motor power: 3 kW; spindle diameter: 40 mm;
spindle speed: electronically variable (with brake) from 3,000 to 6,000 rpm.
Max. tool cutting circle: 400 mm
Axial adjustment: 150 mm via NC axis
Radial adjustment: pneumatic, to 8 positions for top edge rounding
Horizontal bottom rounding unit
-----
Axial adjustment travel: mechanically coupled with cut-off saw
1st Tenoning and Slotting Spindle
-----
Robezawizjybq A Nxjch
Motor power (with brake): 15 kW
Spindle diameter: 50 mm
Spindle speed: 2,925 rpm
Max. tool cutting circle: 400 mm
Tool clamping length: 640 mm
Axial adjustment travel: NC axis
Home position (below table): 5–10 mm
Radial adjustment travel: fixed
2nd Tenoning and Slotting Spindle
-----
Motor power (with brake): 11 kW
Spindle diameter: 50 mm
Spindle speed: 2,925 rpm
Max. tool cutting circle: 400 mm
Tool clamping length: 320 mm
Axial adjustment travel: NC axis
Radial adjustment travel: NC axis
Home position (below table): 5–10 mm
1st Profiling Spindle (Climb and Conventional Milling)
-----
Motor power (with brake): 11 kW
Spindle diameter: 50 mm
Spindle speed: 6,000 rpm
Tool cutting circle: 140 mm
Max. tool diameter: 232 mm
Tool clamping length: 400 mm (with outboard bearing)
Axial adjustment travel: 350 mm (NC axis)
Radial adjustment travel: NC axis
Home position (below table): 5–10 mm
2nd Profiling Spindle
-----
Motor power: 11 kW
Spindle diameter: 50 mm
Spindle speed: 6,000 rpm
Tool cutting circle: 140 mm
Max. tool diameter: 232 mm
Tool clamping length: 400 mm (with outboard bearing)
Axial adjustment travel: 350 mm (NC axis)
Radial adjustment travel: NC axis
Home position (below table): 5–10 mm
Horizontal Profiling Unit (Top)
-----
Motor power (with brake): 3.0 kW
Spindle diameter: 40 mm
Clamping length: 40 mm
Spindle speed: 5,850 rpm
Max. tool cutting circle: 130 mm
Pneumatic adjustment: 8 positions (axial and radial)
3rd Profiling Spindle
-----
Motor power: 11 kW
Spindle diameter: 50 mm
Spindle speed: 6,000 rpm
Tool cutting circle: 140 mm
Max. tool diameter: 232 mm
Tool clamping length: 400 mm (with outboard bearing)
Axial adjustment travel: 350 mm (NC axis)
Radial adjustment travel: NC axis
Home position (below table): 5–10 mm
Vertical Profiling Unit (Right, at Machine End)
-----
Motor power (with brake): 3.0 kW
Spindle diameter: 40 mm
Clamping length: 160 ...
